Page 29
5.13 Run Button
The black “Run” Button (Figure.19-E) is located under the Lamp cover and serves to
initiate the functions as described in the following table;
Function Action
Activate XTrac Momentary press
Safety Beam override Press and hold until garage door is
fully closed
Sleep Mode Press and hold in conjunction with
“Learn” Button
5.14 Safety Beams
The CENTURION i5 or other four wire Safety Beams may be connected to the
XTrac.
The installation of Safety Beams greatly enhances safety by constantly monitoring
for persons or objects which may pass within the path of the moving garage
door.
The XTrac will commence to Safety Reverse if the Safety Beams become
momentarily or permanently interrupted during a Close Cycle
Mounting
Mark the inside garage door framing so that the bottom edge of the i5 beam sits
125mm off the floor
Using a small angle bracket fasten each beam to the wall so that they face each
other across the garage door
Connection
Follow Safety Beam instructions and connect to the Output Terminals depicted in
Figure.14A/B. Use the normally-open contacts of the beam to connect to input SB4
on the XTrac (Figure 14A/B)
Important note: XTrac provides 24VDC output and Normally-Open input.
Alignment
Adjust the Safety Beam module marked “Transmitter” (by turning the mounting
bracket) so that it is aimed directly at the lens of the Safety Beam module marked
“Receiver”. A GREEN indicator lamp located on the “Receiver” will glow once the
correct alignment has been achieved
Test the Safety Beam alignment several times each time ensuring that when the
Safety Beams are obstructed the green indicator lamp extinguishes and when
unobstructed the indicator lamp glows solid
Firmly tighten the Safety Beam mounting bracket fixing screws
Installation of the Safety Beams is now complete
Enabling
Remove the Courtesy Lamp and Control Box Covers to expose the Control Board
(Refer Section.5.6 for removal and replacement details)
Select dipswitch 2 (SB) to the “ON” position (Figure.17)
Replace the Control Box and Courtesy Lamp Cover
LED Colour
Provides visual indication of whether power supply is active or not;
Colour Indicator
Green Power supply active
Red Power supply inactive
