Page 24
5.6 Courtesy lamp
The in-built Courtesy Lamp will switch on each time the XTrac is activated and
then switch off automatically 90 seconds after receiving the last Hand Transmitter
or run signal.
In order to conserve remaining battery power the Courtesy Light will not function
once battery voltage falls below 24V DC.
Bulb replacement
Hinge open the Courtesy Lamp Cover to expose the bulb (Figure.19-A)
Remove the bulb by first pushing-in and then turning anti clockwise (same as
removing and replacing a household light bulb)
Replace bulb with identical 24V 21W Incandescent
Close the Courtesy Lamp cover
Replacing the bulb with 12V version will cause the transformer to overheat
and may permanently damage the transformer and Control Board. Always
ensure that replacement bulb is rated at 24V and no more than 2W.
5.7 Dipswitches
The Dipswitches located on the Control Board (Figure.18) enable or disable
specific functionality
The Dipswitches can be accessed by removing the Courtesy Lamp and Control
Box Covers (Refer Section.5.6 for removal and replacement details)
Read through the following table and select the specific functionality best suited
your specific personal or garage door requirements.
Enabling
Remove the Courtesy Lamp and Control Box Covers to expose the Control Board
(Refer Section.5.6 for removal and replacement details)
Select the Dipswitches as required to enable the desired functionality (Figure.17)
Replace the Control Box and Courtesy Lamp Covers
Functionality table
Function Dip No. Dip Position Details
Adaptive Mode (A/M) – Enable 1 ON Section.4.2.1
Manual Mode (A/M) – Enable 1 OFF Section.4.2.2
Safety Beams (SB) - Enable 2 ON Section.5.14
Safety Beams (SB) – Disable 2 OFF Section.5.14
Autoclose (AC) - Enable 2 & 3 ON Section.5.2
Autoclose (AC) – Disable 3 OFF Section.5.2
Door Service Monitor (DSM) – Enable 4 ON Section.5.8
Door Service Monitor (DSM) – Disable 4 OFF Section.5.8
For future functionality 5 ON N/A
For future functionality 5 OFF N/A
Back Jump (BJ) – Enable 6 ON Section.5.3
Back Jump (BJ) – Disable 6 OFF Section.5.3
