REMOVAL • INSTALLATION
Tightening torque T=Nm
Removal procedure
1. Remove the foot board
2. Set the mast to the vertical position
3. Disconnect the hoses (after lowering the remaining pressure in the tilting cylinders by operating the
tilting lever a number of times)
4. Remove the tilting cylinder front pin [Point 1]
5. Remove the tilting cylinder rear pin [Point 2]
6. Remove the tilting cylinder
Remarks:
If both tilting cylinders are removed fix the mast with a
chain in order to avoid the mast overturning
Installation procedure
The reassembly procedure is the reverse of the disassembly procedure.
Remarks:
• Apply grease to the insertion portions of the tilting cylinder front and rear pins before
installation
• After installation, slowly tilt the mast forward and backward a few times without charge to bleed
the air in the hydraulic circuit and to check the normal functioning
• Check the hydraulic oil level and add if insufficient
