CESSNA AIRCRAFT COMPANY FOR TRAINING USE ONLY
MODEL 152 6-14
ITEM NO
EQUIPMENT LIST DESCRIPTION
REF DRAWING
WT LBS
ARM INS
A. POWERPLANT & ACCESSORIES
A01-R
ENGINE, LYCOMING O-235-L2C (INCLUDES
STARTER, CARBURETOR, SPARK PLUGS AND
ALTERNATOR BRACKETS)
0450071
243.5
-19.2
A05-R
FILTER, CABURETOR AIR
C294510-0201
0.5
-16.0
A09-R
ALTERNATOR, 60 AMP, 28 VOLT (BELT DRIVE)
C611503-0102
10.7
-27.5
A17-R
OIL COOLER INSTALLATION
0450071
3.6*
-22.6
OIL COOLER (STEWART WARNER)
8406J
2.0
-27.5
A21-A
OIL FILTER INSTALLATION (SPIN-ON ELEMENT)
0450412
2.5
-6.0*
A33-R
PROPELLER INSTALLATION
0450077
24.9*
-36.5*
PROPELLER, MCCAULEY FIXED PITCH
1A103/TCM6958
C161001-0501
23.2
-36.5
A41-R
SPINNER INSTALLATION, PROPELLER
0450077
2.4*
-38.6*
SPINNER DOME
0450073-1
0.8
-38.4
AFT BULKHEAD (BACK SIDE OF PROP)
0450072-1
1.1
-38.3
FWD BULKHEAD (FWD SIDE OF PROP)
0450076-1
0.3
-37.4
A61-A
VACUUM SYSTEM INSTALLATION, ENGINE DRIVEN
0413466-1
4.8*
-1.5*
DRY VACUUM PUMP
C431003-0101
2.8
-7.0
FILTER ASSEMBLY
1201075-2
0.3
2.0
VACUUM GAUGE
C668509-0101
0.1
18.0
VACUUM RELIEF VALVE
C482001-0401
0.5
1.9
A70-S
ENGINE PRIMING SYSTEM
0.5
3.1
A73-A
VALVE, ENGINE OIL QUICK DRAIN (NET CHANGE)
1701015-1
0.0
--
B. LANDING GEAR & ACCESSORIES
B01-R-1
WHEEL, BRAKE & TIRE ASSY, 6.00-6 MAIN (2)
C163018-0201
40.3*
46.8*
WHEEL ASSEMBLY, MCCAULEY (EACH)
C163005-0101
7.4
47.1
BRAKE ASSEMBLY, MCCAULEY (LEFT)
C163032-0111
1.7
43.7
BRAKE ASSEMBLY, MCCAULEY (RIGHT)
C163032-0112
1.7
43.7
TIRE, 4-PLY BLACKWALL (EACH
C262003-0101
8.5
47.1
TUBE (EACH)
C262023-0102
1.8
47.1
B01-R-2
WHEEL, BRAKE & TIRE ASSY, 6.00-6 MAIN (2)
1241156-40
37.6*
46.8*
WHEEL ASSY, CLEVELAND 40-113 (EACH)
C163001-0101
6.2
47.1
BRAKE ASSY, CLEVELAND 30-75A (LEFT)
C163030-0111
1.9
43.7
BRAKE ASSY, CLEVELAND 30-75A (RIGHT)
163030-112
1.9
43.7
TIRE, 4-PLY BLACKWALL (EACH)
C262003-0101
8.5
47.1
TUBE (EACH)
C262023-0102
1.8
47.1
B04-R-1
WHEEL & TIRE ASSY, 5.00-5 NOSE
C163018-0101
8.7*
-10.8*
WHEEL ASSY, MCCAULEY
C163005-0201
3.4
-10.8
TIRE, 4 PLY BLACKWALL
C262003-0102
4.0
-10.8
TUBE
C262023-0101
1.2
-10.8
B04-R-2
WHEEL & TIRE ASSY, 5.00-5 NOSE
1241156-2
8.7*
-10.8*
WHEEL ASSY, CLEVELAND 40-77
1241156-12
3.0
-10.8
TIRE, 4-PLY BLACKWALL
C262003-0102
4.0
-10.8
TUBE
C252023-0101
1.2
-10.8
