Cessna 152 1978 - Page 91

CESSNA AIRCRAFT COMPANY FOR TRAINING USE ONLY
MODEL 152 6-15
ITEM NO
EQUIPMENT LIST DESCRIPTION
REF DRAWING
WT LBS
ARM INS
B10-A
WHEEL FAIRINGS (SET OF 3)
0541225
18.0*
35.3*
NOSE WHEEL FAIRING
0543079
4.1
-9.5
MAIN WHEEL FAIRING (EACH)
0541223
5.9
49.5
BRAKE FAIRINGS (EACH)
0441227
0.6
50.5
C. ELECTRICAL SYSTEMS
C01-R-1
BATTERY, 24 VOLT, 14 AMP HR
0870060-1
27.5
-5.5
C01-R-2
BATTERY, 24 VOLT, 14 AMP HR
C614001-0101
22.8
-5.5
C01-0
BATTERY, 24 VOLT, 17 AMP HR
C614001-0102
24.8
-5.5
C04-R
REGULATOR, ALTERNATOR 60 AMP, 28 VOLT
C611004-0101
0.6
0.5
C07-A
GROUND SERVICE RECEPTACLE
0401021
2.0
-2.0
C16-A
PITOT HEATER
0422355
0.6
21.5
C25-A
LIGHT INSTALLATION, CONTROL WHEEL MAP
0470117-3
0.2
22.5
C43-A
LIGHT INSTALLATION, OMNIFLASH BEACON
0406003-1
1.4*
185.5*
BEACON LIGHT IN FIN TIP
C621001-0102
0.4
210.9
FLASHER POWER SUPPLY IN AFT TAILCONE
C594502-0102
0.5
173.9
RESISTOR (MEMCOR)
OR95-6
0.2
183.4
C46-A
LIGHT INSTALLATION WING TIP STROBE
0401009-1
3.1*
37.8*
STROBE LIGHTS IN WING TIP (SET OF 2)
C622006-0101
0.2
35.5
FLASHER POWER SUPPLIES IN TIPS (SET OF 2)
C622008-0102
2.3
39.5
C49-A-1
LANDING LIGHT INSTALLATION – SINGLE BULB
0401022
1.0
-28.3
C49-A-2
LANDING & TAXI LIGHT INSTL. DUAL BULB
0101022
1.8
-28.3
D. INSTRUMENTS
D01-R
INDICATOR, AIRSPEED
C661064-0107
0.6
17.2
D01-O
INDICATOR, TRUE AIRSPEED
0513279
1.0
18.0
D07-R
ALTIMETER, SENSITIVE
C661071-0101
1.0
17.6
D07-0-1
ALTIMETER, SENSITIVE (20 FT MARKINGS)
(FEET AND MILLIBARS)
C661025-0102
1.0
17.6
D07-0-2
ALTIMETER, SENSITIVE (50 FT. MARKINGS)
(FEET AND MILLIBARS)
C661071-0102
1.0
17.6
D16-A-1
ENCODING ALTIMETER (INCLUDES RELOCATION
OF CONVENTIONAL ALTIMETER)
0401013
2.9
17.0
D16-A-2
ENCODING ALTIMETER, FEET & MILLIBARS
(INCLUDES RELOCATION OF CONVENTIONAL
ALTIMETER)
0401013
2.9
17.0
D16-A-3
ENCODING ALTIMETER, USE WITH TRANSPONDER
(BLIND ENCODER-DOES NOT REQUIRE PANEL
MOUNT)
0401019
1.5
2.0
D19-R
AMMETER
S-1320-5
0.5
18.0
D25-A
CLOCK INSTALLATION
CLOCK, ELECTRIC
0400341
C664508-0101
0.4*
0.3
14.4*
18.1
D28-R
COMPASS
C660501-0102
0.5
20.0
D37-R
INSTRUMENT CLUSTER (LH FUEL & RH FUEL)
C669511-0101
0.6
18.0
D40-R
INSTRUMENT CLUSTER (OIL PRES. & OIL TEMP.)
C669512-0102
0.6
18.0
D64-A
GYRO INSTALLATION (REQUIRES ITEM A61-A)
DIRECTIONAL INDICATOR
ATTITUDE INDICATOR
0413466-1
C661075
C661076
7.1*
2.8
2.1
14.8*
15.6
15.8
