CESSNA
MODEL
R182
SECTION 7
AIRPLANE
& SYSTEMS DESCRIPTIONS
(
erra,nged verticelly.
The airspeed
indicator and
altirneter are located to the
left and right
of
the
gyros,
respectively. The remainder
of
the flight
instruments
aro
located
around the basic
"T".
The fuel
pressure ga,ge,
suction
gage
and
carburetor
air temperatur€
ga,ge
are located
below
tb.e
flight instruments,
and
to the left of the
pilot's
control colurnn.
Avionics
equipment is
stacked
approximately
on the
centerline of
tbe
panel,
with
the
right
side
of
the
panel
containing
the manifold
pressure
gage,
tachome-
ter, map comparfu€nt,
and space for
additional instruments
and avionics
eguipment.
The engine
instrument cluster and fuel
quantity
indicators are
on tbe
right side
of the
avionics stapk
near the
top of the
panel.
A sqritch and
control
panel, at the lower
edge of the instrument
panel,
contains most of
the switches,
controls,
and circuit breakers
necessary
to operate
the
ai4rlane.
The
teft side of
the
panel
contains the master switch,
engine,
primer,
auxiliary
fuel
pump
switch, ignition switch, light intensity
controls, electrical
switches,
circuit breakers;,
landing:
gear
indicator
lights and
landing
gear
leveJ. The center'area containg the carburetorheat
control,
throttle,
propeller
control,
and mixture controL The
right side,of
the
panel
contains
the
wi'ng flap switch and indicator, cabin heat,
c,abin
air,
and
defroster
control
knobs
and the
cigar
ligbter. A
pedestal,
extending
from the switch
and control
panel
to the floorboard, contains the
elevator
and rudder trim
control
wbeels, cowl
flap"control lever,,
and
microphone
bracket. The
fuelselector
valve
handle is located
at the base ofthe
pedestal.
A
parking
brake
handle
is
mounted
under the switch
and
control
panel,
in
front of
the
pilot.
A
static
pressure
alt€rnate source valve
control
knob
may also be
installed
below the switch
and
control
panel
adjacent
to the
parking
brake
handle.
For details
concerning
the
instruments, switches, circuit
breakers,
and
controls
on this
panel,
refer
in this section to the description of the systems
to which
these
items
are related.
GROUND
CONTROL
Effective
ground
control
inife taxiing is accomplished
through
nose
wheel steering
by using the
rudder
pedals;
left
rudder
pedal
to steer left and
right
rudder
pedal
to steer right. When a rudder
pedal
is depressed, a
spring-loaded
steering
bungee
(which
is connected to the nose
gear
and
to
the rudder bars)
will turn
the nose
wheel
through an arc of approximately
15o each side
ofcenter.
By applying
either
left or right brake, the degree of
turn ma,y
be
increased
up to 30" each side of center.
Moving the
airplane by
hand
is most
easily
accomplished
by
attaching
a
tow
bar
to the
nose
gea,r
strut.
If a tow bar is not available,
or
pushing
is
required,
use
tho wing struts
as
push points.
Do not
use the vertical
or
horizontal
surfaces
to move the airplane. If the airplane is to
be
towed by
7-9
