2.2 True Monaural setup
In this setup, two P1s enclosures are used to hold a single channel each (Left respectively Right). The entire power supply of each
P1 is dedicated to one channel, further enhancing the system performances. Both P1s should be connected to a network via a
router to ensure all audio settings (such as gain, selected input, cartridge laoding) are synchronized between units. For ultimate
performances, up to two X1 External Power Supply unit should be added to the setup.
True Monaural setup
10 P1 User Manual Rev 1.1
Balanced XLR cables
Turntable
P1 Right True Monaural Phonostage P1 Left True Monaural Phonostage
L1 Right True Monaural Preamplifier L1 Left True Monaural Preamplifier
Balanced XLR cables
XLR or RCA cables
XLR or RCA cables
Router with DHCP server
RJ45 Ethernet cables
