CH P1 - INSTALLED OPTIONS Menu; NETWORK SETTINGS Menu

INPUT NAMES Default names None Set back all input names to their default value
GAIN SELECTION
WIZARD
Start wizard Track 1 on side 2 of the
CH Precision P1
phonostage calibration
record must be used
This wizard helps obtaining the best signal to noise
ratio and a P1 output level close to standard line
level sources (such as the CH Precision C1 DAC)
MM/MC LOADING
WIZARD
Start wizard Track 1 on side 1 of the
CH Precision P1
phonostage calibration
record must be used
More details on that wizard can be found in chapter
1.3 and 8.4.
NETWORK
KNOWLEDGE
Reset None Clears the P1's memory of other CH Precision
devices it has discovered through the TCP/UDP
proprietary protocol.
7.5 INSTALLED OPTIONS menu
PARAMETER PARAMETER VALUES REMARKS
TOP SLOT Left or Right phono board Parameters are Read Only
BOTTOM SLOT
7.6 NETWORK SETTINGS menu
PARAMETER PARAMETER VALUES REQUIRED OPTIONS REMARKS
STATUS IP address
Product type
MAC address
Connection to a router
via its RJ-45 Ethernet
port
List of CH Precision devices and Android remote
controls detected by the P1 (product type, IP and
MAC addresses)
Parameters are Read Only
ROLE Offline
Power master
master
Slave
Custom
Connection to a router
via its RJ-45 Ethernet
port
When physically connected to a network, the P1 can
ignore this network (offline) or connect to it as
being the master (it will broadcast its state for
slaves to synchronize) or as a slave (it will ignore IR
remote control commands and synchronize to the
master instead). When set as power master, even
the on/off state of this unit will be imposed to
slaves.
Custom allows to fine tune which specific parameter
is synchronized though the network.
This networking facility enables information sharing
among CH products (such as input selection, gain
setting and cartridge loading for true monaural P1
Left + P1 Right configurations).
Rev 1.1 P1 User Manual 29
