11 Specifications
General
User control Front panel push-buttons and/or CH Control Android App
Display 480×272 24bits RGB AMOLED
Power supply Selectable 100V, 115V or 230V AC, 47Hz to 63Hz
Power consumption (Standby) < 1W
Power consumption (Normal operation) 40W average
Operating conditions Temperature: +5C to +35C, humidity: 5% to 85% (no condensation)
Dimensions (W x D x H) 440mm x 440mm x 120mm (main body)
440mm x 480mm x 133mm (overall including connectors and feet)
Weight 20kg
Firmware update / Control USB port for firmware update / Ethernet based system control
Playback equalization filters
Defaults equalization filters RIAA, enhanced RIAA
Optional equalization filters EMI, Columbia, Decca and Teldec
Equalization filters accuracy ±0.1dB
High Pass Filter (Bypassable)
Filter Order 3rd order (-18dB per octave)
Cut-off frequency 10Hz
Current inputs
Connections 1x RCA, 1x XLR per channel on each input
Input impedance <0.1 Ohms
Gain for a 1 Ohm internal resistance cartridge (at 1
kHz)
+70dB (P1 gain setting: I/V+0dB)
+75dB (P1 gain setting: I/V+5dB)
+80dB (P1 gain setting: I/V+10dB)
Gain for a 10 Ohm internal resistance cartridge (at 1
kHz)
+65dB (P1 gain setting: I/V+15dB)
+70dB (P1 gain setting: I/V+20dB)
+75dB (P1 gain setting: I/V+25dB)
Voltage input
Connections 1x RCA, 1x XLR per channel
Gains (at 1kHz) +35dB, +40dB, +55dB, +60dB, +65dB, +70dB
Input impedance (cartridge load) Variable from 100 kOhms to 20 Ohms in over 500 steps
Analog outputs
