Balanced outputs 1x XLR per channel
Single-ended outputs 1x RCA, 1x BNC per channel
Output level Up to 8Vrms (balanced), Up to 4Vrms (unbalanced)
Performances
Frequency response (-3dB point) > 400kHz (RIAA equalization filter disconnected), current input selected
Equivalent input noise (EIN) Without the X1 External power supply connected to the P1:
Current inputs: <-135dBu; 1 Ohm termination, gain +70dB, 22kHz BW
Voltage input: <-130dBu; 1 Ohm termination, gain +70dB, 22kHz BW
With the X1 External power supply connected to the P1:
Current inputs: <-138dBu; 1 Ohm termination, gain +70dB, 22kHz BW
Voltage input: <-135dBu; 1 Ohm termination, gain +70dB, 22kHz BW
Total Harmonic Distortion + Noise (THD+N) <0.01%, 1kHz, output level 3Vrms, 22kHz BW
Design and Specifications subject to change without notice. Weight and dimensions are approximate
Illustrations are informative only and may differ from the actual production model
Enclosure designed by Mana Ishoni
FCC-Notice
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
adjust or relocate the receiving antenna
increase the separation between the equipment and the receiver
connect the equipment into a mains outlet on a circuit different from that to which the receiver is connected
consult the dealer or an experienced ratio/TV technician for help
Disposal – Environmental care
Directive 2002/96/EG of the European Parliament requires consumer electro-technical appliances to be
disposed separately and have to be indicated with the following symbol. Should you dispose this
component please do so in conformity with local and global legal and environmental regulations and
according to best practices. We strongly encourage you to recycle any batteries used with this component.
Rev 1.1 P1 User Manual 35
