I/V + 5 dB
I/V + 10 dB
I/V + 15 dB
I/V + 20 dB
I/V + 25 dB
MC current input
MC current input
MC current input
MC current input
MC current input
impedance MC cartridges connected to the MC1 or
MC2 input. The lower the cartridge resistance is, the
lower the gain setting can be.
MM/MC LOADING 20 Ohm
…
100 kOhm
more than 500 values
available
MM/MC voltage input
only
Follow the cartridge manufacturer's
recommendation, and use the loading wizard
detailed in chapter 1.3 and 8.4 to refine that value.
See chapter 7.4 to find this setting.
7.2 DISPLAY SETTINGS menu
PARAMETER PARAMETER VALUES REQUIRED OPTIONS REMARKS
DISPLAY MODE Status
Off
Dim
None Allows to chose the display's behavior; stay fully on
at user-defined brightness, turn off after a few
seconds of dim after a few seconds.
LED ON/OFF On
Off
None Allows to select if the LED is off or on when the P1 is
on
INPUT RENAMING
Any string
None Used to rename any input in the P1
BRIGHTNESS 10%
20%
…
90%
100%
None Sets the display brightness
COLOR Red
Green
Blue
White
Yellow
Magenta
Cyan
Custom color
Edit custom color
None Selects the display color
Custom color is a user definable color. To Edit the
custom color select the Edit custom color Value. Sub-
menus allow to individually configure Red, Green
and Blue components (RGB) of the custom color.
GAMMA RBG and global
brightness gamma curve
correction, +/-30%
None Fine adjustment the gamma scale of the RGB
components of the display. Allows to have perfectly
dark background and to match other CH Precision
unit's display color, even at low brightness
Rev 1.1 P1 User Manual 27
