FY –33VC Operation manual
- 14 -
Figure 4-7 Assistant ink tanks
Figure 4-8 Cleaning operation panel
1. Print head：8 piezo print heads
2. Media：A wide range of media available
3. Printing Platform：Platform for printing
4. Power Switch：Turn on/off printer
5. Press Roller Control Pole：Control press roller up / down for media feeding
6. LCD Control Panel：Set up and execute function and mode
7. Heating board：Heat media to dry the ink on the media
27
28
32
31
30
