79028569 A Rev. 01-7
Torque Charts
TORQUE CHARTS
SPECIAL TORQUES
Description Bolt and Nut
(Hardness)
Torque
Nm (ft.-lbs.)
Front Axle - 4WD
Axle bracket - engine bolt torque M14 (7T) 127-147 (94-109)
Front pivot casting (support) - bolt torque M12 (7T) 88-108 (65-80)
Rear pivot casting (support) - bolt torque M18 (7T) 119-136 (88-101)
Front axle final drive - bolt torque M12 (7T) 88-108 (65-80)
Bearing cover - bolt torque M8 (7T) 24-33 (18-25)
Wheel shaft cover - bolt torque M10 (7T) 54-69 (40-51)
Front wheel - bolt torque M16 (7T) 157-176 (116-130)
Bevel gear case - bolt torque M8 12-17 (9-13)
Differential Support - bolt torque M8 12-17 (9-13)
Rear gear - differential support-bolt torque M8 12-17 (9-13)
Bevel pinion lock nut See torque procedure - chapter 6A
Transmission
Front transmission to engine bolts nuts M12 (7T) 88-108 (65-80)
Front transmission to spacer transmission - bolts and nuts M12 (7T) 88-108 (65-80)
Spacer transmission to differential housing - bolt and nuts M12 (7T) 88-108 (65-80)
Input housing - bolts and nuts M12 (7T) 88-108 (65-80)
Drive pinion housing - bolts M10 (7T) 54-69 (40-51)
Drive pinion nut See torque procudure - chapter 5A
Differential case - bolts M12 48-68 (36-51)
Differential case - ring gear nuts M10 (7T) 54-69 (40-51)
Rear Axle
Rear axle to differeintal housing bolts M10 (7T) 54-69 (40-51)
Brake housing - bolts M10 (7T) 54-69 (40-51)
Rear wheel - bolts and nuts M22 363-382 (268-282)
Cylinder Cover and Other
Hydraulic cylinder cover to differential housing bolts and nuts M10 (7T) 54-69 (40-51)
Hydraulic cylinder head bolts M12 (7T) 88-108 (65-80)
Hydraulic control valve bolts M8 12-17 (9-13)
Lower link bracket bolts and nuts M14 69-78 (51-58)
