Chamberlain T User Manual

©
2004, The Chamberlain Group, Inc.
All Rights Reserved
01-30961A
OPEN / CLOSE
3 BUTTON STATION OR 3 POSITION KEYSWITCH WITH SPRING RETURN TO CENTER AND STOP BUTTON
2 OR MORE KEY LOCKOUT
R1 R2 R3
7 6 4 5
Stop
Close
Open
Stop
Close
Open
7 6 4 5
Stop
Close
Open
2 BUTTON STATION OR 3 POSITION KEYSWITCH WITH SPRING RETURN TO CENTER
STANDARD
7 6 4
Close
Open
D1 & E2
MODE ONLY
2 OR MORE
7 6 4
Close
Open
Close
Open
D1 & E2
MODE ONLY
OPEN / CLOSE
1
4
B2, T, TS & FSTS
MODE ONLY
Any Commercial Type
LiftMaster Brand Receiver
1 BUTTON STATION OR ANY AUXILIARY DEVICE
RADIO CONTROLS
SENSING DEVICE TO REVERSE OR STOP
EXTERNAL INTERLOCK
11
8
2
3
2
3
Remove Factory Installed Jumper
When Interlock is Used
ONE 2 OR MORE
STANDARD
7 6 4 5
Stop
Close
Open
IMPORTANT NOTES:
The 3-Button Control Station provided must be connected for operation.
If a STOP button is not used, a jumper must be placed between terminals 4 and 5.
All Wiring Types
Keyswitch
Sensing Device
10
Maintenance
Alert LED
10 10
Maintenance
Alert LED
Maintenance
Alert LED
(RED)
(WHITE)
(RED)
(WHITE)
(RED)
(WHITE)
Note: 11 & 4 are both the same common
Either is acceptable
See Note
See Note
See Note
CONTROL CONNECTION DIAGRAM
