Cleaning

CLEANING

WASH AND PREWASH SPRAY ARMS —

Remove the upper and lower wash/prewash spray arms.

Lift the lower arms and pull forward to remove, Fig.63.

Upper arms have latches, Fig. 64. Press the latch and pull arm forward, Fig. 65.

Fig. 63 - Lift and pull forward to remove lower spray arms.

WASH

PREWASH

Fig. 64 - Press latches to release upper spray arm.

WASH

PREWASH

Fig. 65 - Pull forward and down to remove upper spray arms.
