32
OPTIONAL FRONT FEED —
Optional Front Feed - Setup
CHECK CONVEYOR ARM AND RACK SWITCHES —
SET
UP
Make sure the rack switch and idle pump switch, and conveyor pawls move freely, Fig.79.
1
Fig. 78 -
Front feed machines receive dish racks into the front of the machine.
• The front feed option allows dish racks to be loaded into the front of the machine, Fig. 78.
Rack switch
Fig. 79 -
Switches and pawls must move freely.
Pawl
Rack switch
