Two cable lengths are available:
o
Standard length cables are 5.4 m (17 ft 8 1/2 in) long and are used with standard Cable
Management Kits (CMK)
o
Medium length cables are 7.6 m (24 ft 11 1/4 in) long and are used with longer cable
management systems
IMPORTANT: Place each charging station to maximize cable reach for the varied charge port
locations on different EVs.
Commercial or Public Station Placement, Single or Dual Cable
a. Cable reach radius: 3.76 m (12 ft 4 in)
5
