DELETING THE LIMIT SWITCH POSITIONS
During operation, the control unit automatically acquires the mechanical limit switch
positions set on the motor. In the event that the length or position of the mechanical limit
switches need to be changed, the positions already acquired by the control unit will need
to be deleted.
At the end of the sequence, the control unit is ready to automatically acquire the new
limit switch positions.
ATTENTION! This operation deletes all the memorized middle positions.
4 sec
SETTING OF ADDITIONAL REMOTE CONTROLS
Up to 15 remote controls can be set, including the light/wind sensor.
Tn: Already programmed remote control
Tx: Additional remote control
TnTn Tx (2 sec)
ENGLISH
+ CB + CB + CB
+
B C
+
B C
+
B C
+
A
B
+
A B
B
B
