Digital Color Doppler Palm Ultrasound System
35
4. To edit existed comment, press and hold it, the soft icon board appears, the user can re-input comment.
5.4.2 Adding BodyMark
Operation:
1. Freeze image and slide the menu list to select .
2. The secondary menu appears, press
. The body mark list displays, select the body mark in desired
application. The body mark displays in image area.
3. Slide the blue dot to adjust the probe direction.
4. To move the body mark, press it and move it to target position.
5.4.3 Adding Mark
Operation:
1. Freeze image and slide the menu list to select .
2. The submenu appears, press
. The mark displays in image area.
3. Slide the blue dot to adjust the mark direction.
4. To move the mark, press it and move it to target position.
