Chison SonoEye P2 - B Mode Measurement; B;M Mode Measurement

Digital Color Doppler Palm Ultrasound System
37
appears in image area. Use a finger to slide on the top right or left corner to adjust location, press image
area to finish measurement. The measurement results display on result area.
Meas. item name
mark
unit
Meas. Method and calc. formula
IMT(Auto)
Max
Min
Mean
Std
cm
Refer to Auto IMT in 6.2.1
StA%
A Out
cm
2
Refer to “Ellipse” measurement in 6.1
A In
cm
2
Refer to “Ellipse” measurement in 6.1
StA%
%
StA%=
（
A Out-A In
）
/ A Out*100%
StD%
D Out
cm
Refer to “Distance” measurement in 6.1
D In
cm
Refer to “Distance” measurement in 6.1
StD%
%
StD%=
（
D Out-D In
）
/ D Out*100%
6.2.2 Small Organ Measurement in B mode
Meas. item
name
mark
unit
Meas. Method and calc. formula
Thyroid Vol.
Length
cm
Refer to “Distance” measurement in 6.1
Width
cm
Refer to “Distance” measurement in 6.1
Height
cm
Refer to “Distance” measurement in 6.1
Volume
ml
Volume=Length*Width*Height*3.14159265/6
6.3 B/M Mode Measurement
1. Distance
This feature allows the measurement of the distance between two points. It is a measurement between the
two horizontal lines that lean on the two cursors. The position of the vertical time line does not affect the
distance measurement.
Distance measurement is the same as distance measurement in B mode.
2. Time
Time is the measurement between the two vertical time lines created by two cursors. The position of the
horizontal distance line does not affect time measurements.
3. HR
HR is the measurement between the two vertical lines that are created by two cursors in beat per minute
(BPM). The position of the horizontal distance line does not affect HR.
