Chroma 62006P-100-25 User Manual

Program Sequence
(3) Setting Sequence Type to EXT. TRIGGER
When SEQ TYPE = EXT. TRIGGER is set, the Sequence page shown as Figure 4-14
indicates the sequence will run automatically and stop at the setting of VOLTAGE or
CURRENT without skipping to next sequence until triggered by positive pulse from PIN
7 of Analog Interface on the rear panel. It will not ask users to enter the time the
sequence will remain when set to EXT. TRIGGER.
[ S E Q U E N C E ]
S E
Q
N
O
. = 1 S E
Q
.T
Y
PE=EX
T
.T
R
I
G
G E R
V
O
L T
A
G
E = 0
V
S.
R
.=1.0(V/
m
S )
C
U
R
R
E N
T
= 0 I S.
R
.=1.0(A/
m
S )
T T L
O
U
T
= 0 <BINAR
Y
=00000000 >
▲
▼
Figure 4-14
3. Press “
ENTER
” to confirm.
4. Press “
EXIT
” to return to Program PAGE (Figure 4-1).
4.2.3 Setting Voltage
1. Use “
”, “
” keys to move the cursor to the column to be set as Figure 4-9 (3)
shows.
2. Use the numeric (
0
~
1
) keys or “Rotary” ( ) knob to set the SEQ output voltage
3. Press “
ENTER
” to confirm.
4. Press “
EXIT
” to return to Program PAGE (Figure 4-1).
See section 3.2 for detail description of settings.
4.2.4 Setting Current
1. Use “
”, “
” keys to move the cursor to the column to be set as Figure 4-9 (4)
shows.
2. Use the numeric (
0
~
1
) keys or “Rotary” ( ) knob to set the SEQ output current
limit.
3. Press “
ENTER
” to confirm.
4-13
