Chroma 69200-1 User Manual

Charge/Discharge Controller 69200-1 User’s Manual
1-2
1.2.4 Measuring & Editing
• The system has to use Chroma 69200-x controller (option) or to work with software to do
output current, voltage and power measurements.
• The system has to use Chroma 69200-x controller (option) or to work with software to
edit output Program and Waveform, etc.
1.3 Specification
Chroma 69200-x is the controller without power stage. It is mainly for the user to set the
charge/discharge mode and program to control other DC/DC power stage (Regenerative
Charge/Discharge Tester). A Controller is able to control 60 channels and receive the
charge/discharge test sequences from PC, also to save the test results of Regenerative
Charge/Discharge Tester and return to PC.
1.4 Function Keys
1.4.1 Front Panel
Figure 1-1 Front Panel

Chroma 69200-1 Specifications

General

Brand	Chroma
Model	69200-1
Category	Controller
Language	English
