Charge/Discharge Controller 69200-1 User’s Manual
3-32
Command
Parameter
Description
PROCess:TIME:STATe?
None
Query the count mode of execution time.
Syntax: PROCess:TIME:STATe?
Parameter: None
Return Value: OFF
SYST:ERR? Error Messages
0, (CHAR *)"\"No error\"", //MSG_NO_ERR
-101, (CHAR *)"\"Invalid character\"", //MSG_INVALID_CHAR
-102, (CHAR *)"\"Syntax error\"", //MSG_SYNTAX_ERR
-103, (CHAR *)"\"Invalid separator\"", //MSG_INVALID_SEPARATOR
-104, (CHAR *)"\"Data type error\"", //MSG_DATA_TYPE_ERR
-105, (CHAR *)"\"GET not allowed\"", //MSG_GET_NOT_ALLOWED
-106, (CHAR *)"\"Illegal parameter value\"", //MSG_ILLEGAL_PARA_VAL
-108, (CHAR *)"\"Parameter not allowed\"", //MSG_PARA_NOT_ALLOWED
-109, (CHAR *)"\"Missing parameter\"", //MSG_MISS_PARA
-112, (CHAR *)"\"Program mnemonic too long\"", //MSG_PROG_MNEM_TOO_LONG
-113, (CHAR *)"\"Undefined header\"", //MSG_UNDEF_HEADER
-121, (CHAR *)"\"Invalid character in number\"", //MSG_INVALID_CHAR_IN_NUM
-123, (CHAR *)"\"Numeric overflow\"", //MSG_NUM_OVERFLOW
-124, (CHAR *)"\"Too many digits\"", //MSG_TOO_MANY_DIGITS
-131, (CHAR *)"\"Invalid suffix\"", //MSG_INVALID_SUFFIX
-141, (CHAR *)"\"Invalid character data\"", //MSG_INVALID_CHAR_DATA
-148, (CHAR *)"\"Character data not allowed\"", //MSG_CHAR_DATA_NOT_ALLOWED
-151, (CHAR *)"\"Invalid string data\"", //MSG_INVALID_STR_DATA
-158, (CHAR *)"\"String data not allowed\"", //MSG_STR_DATA_NOT_ALLOWED
-203, (CHAR *)"\"Command protected\"", //MSG_COMMAND_PROTECTED
-211, (CHAR *)"\"Data stale\"", //MSG_DATA_STALE
-221, (CHAR *)"\"Setting conflict\"", //MSG_SET_CONFLICT
-222, (CHAR *)"\"Data out of range\"", //MSG_DATA_OUT_RANGE
-223, (CHAR *)"\"Too much data\"", //MSG_TOO_MUCH_DATA
-224, (CHAR *)"\"Self-test failed\"", //MSG_SELFTEST_FAILED
-225, (CHAR *)"\"Too many errors\"", //MSG_TOO_MANY_ERRORS
-410, (CHAR *)"\"INTERRUPTED\"", //MSG_INTERRUPTED
-430, (CHAR *)"\"DEADLOCKED\"", //MSG_DEADLOCKED
-440, (CHAR *)"\"UNTERMINATED\"", //MSG_UNTERMINATED
3.3.8.2 CC Discharge Mode Operation
Description: When the operating channel is 1 and the current slew rate is set to 1.00A/ms,
1A is fixed for discharging until the voltage is 2.500V.
Single unit settings:
I 1.000 (Constant Current must be setup)
V C U T 2.500 (Cutoff Voltage must be setup)
T I M E 0 (Testing time must be setup, “0” means no time limit)
P 4.00 (Power limit must be setup)
S.R. 1.00 (Current Slew Rate must be setup)
V 2.450 (must < VCUT)
I C U T 0 (not necessary, set as “0”)
