Cavity Cartridge Fuse Blade Fuse Description
F67 – 10 Amp Red
In Vehicle Temperature
Sensor/Humidity Sensor/
Drivers Assist System Module
(DASM)/Park Assist (PAM) –
If Equipped
F68 – – Not Used
F69 – 10 Amp Red
Gear Shift Module (GSM)/
Active Grill Shutter (AGS). –
If Equipped/EPB SW
F70 – 5 Amp Tan
Intelligent Battery Sensor
(IBS) – If Equipped with En-
gine Stop/Start Option
F71 – 20 Amp Yellow
HID Headlamp Right – If
Equipped with Engine Stop/
Start Option
F72 – 10 Amp Red Heated Mirrors – If Equipped
F73 – – Not Used
F74 30 Amp Pink – Rear Defroster/Defogger
F75 – 20 Amp Yellow Cigar Lighter
F76 – 10 Amp Red
Drivers Window SW– If
Equipped
F77 – 10 Amp Red UCI Port/Brake Pedal Switch
F78 – 10 Amp Red
Diagnostic Port/Steering Col-
umn Control Module
(SCCM)
F79 – 10 Amp Red
Integrated Center Stack
(ICS)/Switch Bank/Instrument
Panel Cluster (IPC)/EPB SW
F80 – 20 Amp Yellow Radio
F81 – – Not Used
F82 – – Not Used
F83 20 Amp Blue –
Engine Control Module
(ECM)
F84 30 Amp Pink –
Electric Park Brake (EPB) –
Left
F85 – – Not Used
F86 – 20 Amp Yellow
Horns – If Equipped With
Engine Stop/Start Option
F87A – 20 Amp Yellow
HID Headlamp Left – If
Equipped Engine Stop/Start
Option
