Instrument Cluster Display Menu Items
NOTE: The instrument cluster display menu items display
in the center of the instrument cluster. Menu items may
vary depending on your vehicle features.
Speedometer
Push and release the up or down arrow button until
Speedometer is highlighted in the instrument cluster dis-
play. Push and release the OK button to toggle between
MPH and km/h.
Vehicle Info
Push and release the up or down arrow button until
Vehicle Info is highlighted in the instrument cluster dis-
play. Push the left or right arrow button to scroll through
the following information submenus:
• Tire Pressure
• If tire pressure is OK for all tires, a vehicle ICON is
displayed with tire pressure values in each corner of the
ICON.
• If one or more tires have low pressure, “Inflate Tire To
XX” is displayed with the vehicle ICON, and the tire
pressure values in each corner of the ICON with the
pressure value of the low tire displayed in a different
color than the other tire pressure value.
• If the Tire Pressure system requires service, “Service Tire
Pressure System” is displayed.
• Tire PSI is an information only function and cannot be
reset.
• Refer to “Tire Pressure Monitoring System (TPMS)”
under “Safety” for further information.
• Coolant Temperature
Displays the actual coolant temperature.
• Oil Temperature
Displays the actual oil temperature.
• Oil Pressure
Displays the actual oil pressure.
• Oil Life (Hold OK Button To Reset)
• The “Hold OK to Reset” instruction will be displayed at
all times, but the following conditions will need to be
met in order to reset Oil Life:
The vehicle must be off
The ignition must be in the ON/RUN position
• If the conditions are met, holding the OK button will
reset the gauge and the numeric display will return to
100%.
190 GETTING TO KNOW YOUR INSTRUMENT PANEL
