Locating The Upper Tether Anchorages
There are tether strap anchorages located behind all
second row seating positions. The third row has
a tether anchor on the 40% seat for the right
outboard position and in the center of the 60%
seat for either the center or left outboard seating
position. All tether anchorages are located on the back of
the seat, near the floor.
LATCH-compatible child restraint systems will be
equipped with a rigid bar or a flexible strap on each side.
Each will have a hook or connector to attach to the lower
anchorage and a way to tighten the connection to the
anchorage. Forward-facing child restraints and some rear-
facing child restraints will also be equipped with a tether
strap. The tether strap will have a hook at the end to attach
to the top tether anchorage and a way to tighten the strap
after it is attached to the anchorage.
LATCH Anchorages (Third Row 60/40 Anchorages Shown) Tether Strap Anchorages (Third Row 60/40 Anchorage
Shown)
300 SAFETY
