Cavity Cartridge Fuse Blade Fuse Description
F15 40 Amp Green – Power Locks
F16 – 20 Amp Yellow ECM
F17 30 Amp Pink – Starter
F18 40 Amp Green – CBC Feed #2 (Exterior
Lights #1)
F19 25 Amp Clear – 2nd Row Folding Seats So-
lenoid LT
F20 – 10 Amp Red A/C Compressor Clutch
F21 25 Amp Clear – 2nd Row Folding Seat Sole-
noid RT
F22 – – Not Used
F23 – – Not used
F24 – 20 Amp Yellow RR Wiper
F25 – 10 Amp Red LT RR Door/RT RR Re-
lease Module/Active Grill
Shutter/Power Mirror
F26 40 Amp Green – Front HVAC Blower Motor
F27 25 Amp Clear – RR Slide Door Module
F28 – 10 Amp Red Diagnostic Port/ USB
Port/ AUX Port/ Video
USB Port
