Cavity Cartridge Fuse Blade Fuse Description
F46 30 Amp Pink – Driver Door Module
F47 30 Amp Pink – Passenger Door Module
F48 – – Not Used
F49 25 Amp Clear – RR Sliding Door Module
F50 25 Amp Clear – RR Door Module
F51 30 Amp Pink – Front Wiper
F52 30 Amp Pink – Brake Vacuum Pump
F53 – – Not Used
F54 40 Amp Green – ESP-ECU And Valves
F55 – 15 Amp Blue Radio Frequency HUB/
Keyless ignition system
(KIN) / (Electronic Steering
Lock-BUX ONLY) DVD /
Video Routing Module
(VRM
F56 – 10 Amp Red Front and Rear HVAC Con-
trol Module/ESP/ESC /
Occupant Classification
Module (OCM)/Electronic
Steering Lock (ESL)
F57 – – Not Used
456 IN CASE OF EMERGENCY
