Cavity Cartridge Fuse Blade Fuse Description
F95B – 10 Amp Red USB Charge Port — Battery
Power
F96 – 10 Amp Red Occupant Restraint Con-
troller (ORC) (Airbag)
F97 – 10 Amp Red Occupant Restraint Con-
troller (ORC) (Airbag)
F98 – 15 Amp Blue Left HID Headlamp
F99 30 Amp Pink – Electrical Brake Module/
Trailer Tow — If Equipped
F100 – 10 Amp Red AHLM/Rear Camera/
LBSS/RBSS/CVPM/
Humidity Sensor/In Ve-
hicle Temperature Sensor
Circuit Breakers
CB1 30 Amp Power Seats (Driver)
CB2 30 Amp Power Seats (Pass)
CB3 25 Amp FRT PWR Window W/O
Door Nodes + RR PWR
Window Lockout
460 IN CASE OF EMERGENCY
