20
Quick Switch between Alarm and Cameras
If you purchased an alarm system & camera kit or any extra camera that has been
purchased along with it, you can connect the camera to your home WiFi by the step-
by-step instructions on the app and then directly viewing the camera on the hub’s main
page.
HomeCloud System
History
Operations and alerts can be reviewed from this history page. Press [ ] at the top
right corner, and tap on the [ ] to access the history page. You can tap on the
[ ] at the top right corner and select a specic day to search for an alert.
Only the most recent 300 alerts will be shown. New alerts will overwrite the oldest ones.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Chuango H4 PLUS and is the answer not in the manual?

Chuango H4 PLUS Specifications

Hub

Power IconPower
power supply voltageDC 12V
power supply current500mA
battery voltage3.7V
battery capacity2600mAh
Operating Environment IconOperating Environment
operating temperature range0°C ~ +55°C
relative humidity<80% (Non-condensing)
Dimensions IconDimensions
hub dimensions160 x 160 x 45mm
bracket dimensions80 x 80 x 10mm

Remote Control

Power IconPower
power supply voltageDC 3V
transmit current<7mA
Operating Environment IconOperating Environment
operating temperature range0°C~+55°C
relative humidity<80% (Non-condensing)
Dimensions IconDimensions
dimensions58 x 31 x 9.5mm

Door/Window Sensor

Power IconPower
power supply voltageDC 1.5V
static current<35uA
alarm current<40mA
Operating Environment IconOperating Environment
operating temperature range0°C~+55°C
relative humidity<80% (Non-condensing)
Dimensions IconDimensions
transmitter dimensions71 x 34 x 17.5mm
magnet dimensions51 x 12 x 13.5mm

PIR Motion Detector

Power IconPower
power supply voltageDC 3V
static current<18uA
alarm current<12mA
Operating Environment IconOperating Environment
operating temperature range0°C~+55°C
relative humidity<80% (Non-condensing)
Dimensions IconDimensions
sensor dimensions108 x 52 x 36.8mm
bracket dimensions52 x 30 x 26.5mm
