CIRCLE M7 - M7 Treadmill Side Rails Replacement

Document: Service Manual
Description: Treadmill
Model: M7 LED
Page: 26 of 60
26
5.4. M7 Treadmill Side Rails Replacement
STEP 1:
Remove the roller cover
by unscrewing the 4
screws on both sides.
STEP 2:
Remove the end cap set
plate by unscrewing the 4
screws on both sides.
STEP 3:
Release 8 bolts
underneath side rail via
M5 Wrench without
loosening
