CIRCLE M7 - Panel of Console Replacement

Document: Service Manual
Description: Treadmill
Model: M7 LED
Page: 21 of 60
21
5.2. Panel of Console Replacement
STEP 1:
Remove the 7 screws to
disassemble the Lower
Console Cover via screw
driver.
STEP 2:
Remove the screws under
the right & left handlebar and
remove the Lower Console
Cover.
STEP 3:
Remove the screws under
the Upper Console Cover to
disassemble.
