5.10. Hand pulse Set Replacement
STEP 1:
Remove the 7 screws to
disassemble the Lower
Console Cover via screw
driver.
STEP 2:
Remove the screws under
the right & left handlebar
and remove the Lower
Console Cover.
STEP 3:
Remove the screws under
the Upper Console Cover
to disassemble.
