YD - Yaw Damper Button (Optional)
The YD button engages/disengages the yaw damper.
• Note •
The yaw damper is automatically engaged when the Autopilot
is engaged with the AP button.
UP/DN - Pitch Wheel
The Pitch UP/DN Wheel on the controller is used to change the Flight
Director pitch mode reference value. Each click of the wheel results in
a step increase or decrease in the Flight Director pitch mode by the
amount shown in the table below. The Pitch Wheel controls the
reference for Pitch Hold (PIT), Vertical speed (VS), and Indicated
Airspeed (IAS) FD modes. The reference value is displayed next to the
active mode annunciation on the PFD. Go-Around and Glidescope
modes are not controlled by the nose Pitch Wheel, however, use of the
Pitch Wheel during Go-Around mode will cause reversion to Pitch Hold
mode. The Pitch Wheel controls altitude reference when in altitude
hold mode.
IAS - Indicated Airspeed Hold Button
The IAS button selects/deselects the Indicated Airspeed Hold mode.
ALT - Altitude Button
The ALT hold button selects/deselects the Altitude Hold mode.
VS - Vertical Speed Button
The VS button selects/deselects the Vertical Speed mode.
VNV - VNAV Button
The VNV button selects/deselects the Vertical Navigation mode.
Flight Director Mode Step Value
Default Pitch Hold (PIT) 0.50 Degree
Vertical speed (VS) 100 Feet per Minute
Indicated Airspeed (IAS) 1 Knot
Altitude Hold (ALT) 10 Feet
Revision 03: 12-14-10
