Cisco 1130AG - Aironet - Wireless Access Point User Manual

2-24
Cisco Aironet 1130AG Series Access Point Hardware Installation Guide
OL-8369-05
Chapter 2 Installing the Access Point
Rotating the Cisco Logo
Rotating the Cisco Logo
The Cisco logo on the top of the unit can be rotated to correctly position the logo for any mounting
arrangement making it always easy to read.
To rotate the Cisco logo, follow these steps:
Step 1 Place the end of an opened paper clip into each of the holes on the logo assembly (see Figure 2-16).
Figure 2-16 Cisco Logo Holes
Step 2
Using the paper clips, rotate the logo until you reach the desired orientation. Detents are provided to help
you align the logo for 90 degree rotations.
Step 3 Remove the paper clips.
1 Status LED 2 Logo assembly holes
121809
2
1
