3-2
Cisco Aironet 1130AG Series Access Point Hardware Installation Guide
OL-8369-05
Chapter 3 Troubleshooting Autonomous Access Points
Checking the Autonomous Access Point LEDs
Checking the Autonomous Access Point LEDs
If your autonomous access point is not working properly, check the Status LED on the top panel or the
Ethernet and Radio LEDs in the cable bay area. You can use the LED indications to quickly assess the
unit’s status. Figure 3-1 shows the access point LEDs (for additional information refer to the Event Log
using the access point browser interface).
Figure 3-1 Access Point LEDs
Note To view the Ethernet and Radio LEDs you must open the access point cover (refer to the “Opening the
Access Point Cover” section on page 2-11).
Note When the access point cover is opened, the Status LED colors are not visible.
Note Regarding LED status colors, it is expected that there will be small variations in color intensity and hue
from unit to unit. This is within the normal range of the LED manufacturer’s specifications and is not a
defect.
1 Status LED 3 Ethernet LED
2 Access point cover 4 Radio LED
121802
4
3
2
1
