Chapter 2 Installing the Access Point
Deploying the Access Points on the Wireless Network
The mounting plate features are described below:
• Keyhole clips—used to attach the access point to the mounting plate. The keyhole clips slide into
the keyhole slots on the bottom of the access point.
• Screw holes (A, B, C)—used to attach the suspended ceiling adjustable T-rail clips.
• Screw hole (X)—used to attach the mounting plate to a network cable box, wall, or ceiling. The
mounting kit contains two 8 x 32 x 1 inch pan head screws and wall anchors for wall or ceiling
mounting.
• T-bar hanger clip hole—used to attach a T-bar hanger clip.
• Security screw hole—used to secure the access point to the mounting plate.
• Padlock hole—used to attach a padlock (user provided) to secure the access point to the mounting
plate. Compatible padlocks are Master Lock models 120T and 121T or equivalent. The security hasp
adapter can also be used with the padlock for increase security protection.
Note The security hasp covers the cable bay area ( including the power port, Ethernet port,
console port, and the mode button) to prevent the installation or removal of the cables or the
activation of the mode button.
Suspended Ceiling Adjustable T-Rail Clip
The accessory kit contains one suspended ceiling adjustable T-rail clip that can be used for standard and
recessed ceiling tile rails. The clip is adjustable to accomodate three standard T-rail widths. The clip
contains detents that are used to adjust the clip to the T-rail. Each detent contains markings that indicate
the T-rail width and the hole letter that corresponds to the correct mounting holes on the mounting plate.
Figure 2-3 shows the details of the adjustable T-rail clip.
