2-7
Cisco TelePresence System 3000
OL-14521-01
Chapter 2 Building the Display Assembly
Parts List
Step 6 Attach the Camera Assembly bracket to the center Display structure.
Figure 2-6 Camera Assembly bracket
Note The Camera Assembly bracket attaches to the center Display structure.
201105
1
9
13
13
