Cisco TelePresence System 3000
OL-14521-01
Appendix A Parts List Sorted by Carton
Carton 37 of 44: Display Structure, 69-1622-xx, CTS3K-STRUCTURE
Carton 37 of 44: Display Structure, 69-1622-xx,
CTS3K-STRUCTURE
Carton 38 of 44: Spare Fluorescent Bulbs for Light Fixture,
74-5232-01, CTS-3000-SPR-BULBS
Carton 39 of 44: Projector Screen, 74-5416-xx, CTS3K-SCREEN
Carton 40 of 44: Display Shelves and Codec Tray, 69-1626-xx,
CTS3K-STRUCTURE
Kit ID Number
Sub-Kit ID
Number Part Number Part Description Qty
Chapter Parts List
Reference
69-1622-xx 700-23358-xx Display structure 1 Chapter 2
Kit ID Number
Sub-Kit ID
Number Part Number Part Description Qty
Chapter Parts List
Reference
74-5232-01 95-9611-01 Spare lights for light fixture 1 Chapter 4
Kit ID Number
Sub-Kit ID
Number Part Number Part Description Qty
Chapter Parts List
Reference
74-5416-xx Projector screen assembly 1 Chapter 7
1
1. Refer to the installation guide that is packaged with the assembly to install the projector screen.
Kit ID Number
Sub-Kit ID
Number Part Number Part Description Qty
Chapter Parts List
Reference
69-1626-xx 700-23339-xx Display shelf support left 3 Chapter 2
700-23340-xx Display shelf support right 3 Chapter 2
700-23341-xx Codec safety tray 3 Chapter 2
