Use appropriate ESD procedures when inserting the transceiver. Avoid touching the contacts at the rear, and
keep the contacts and ports free of dust and dirt. Keep unused transceivers in the ESD packing that they were
shipped in.
Warning
Although non-Cisco SFPs are allowed, we do not recommend using them because they have not been tested
and validated by Cisco. Cisco TAC may refuse support for any interoperability problems that result from
using an untested third-party SFP transceiver.
Caution
The following table lists the supported transceivers for the fixed ports on all 3100 models, and the
FPR-X-NM-8X10G/FPR-X-NM-8X25G network modules.
Table 4: Supported 1-Gb SFP Transceivers
CommentsPIDOptics Type
1 Gb-copper SFP, current versionGLC-TE1G, 1000Base-T
850 nmGLC-SX-MMD1G multimode
1310 nmGLC-LH-SMD1G single mode
40 kmGLC-EX-SMD1G SM extended r.
80 kmGLC-ZX-SMD1G SM
The following table lists the supported transceivers for the fixed ports on all 3100 models and the
FPR-X-NM-8X10G/FPR-X-NM-8X25G network modules.
Table 5: Supported 10-Gb SFP Transceivers
CommentsPIDOptics Type
—SFP-10G-SR10G-SR
Ethernet onlySFP-10G-SR-S10G-SR
—SFP-10G-LR10G-LR
Ethernet onlySFP-10G-LR-S10G-LR
—SFP-10G-ER-S10G-ER
—SFP-10G-ZR10G-ZR
—SFP-10G-ZR-S10G-ZR
x = 1, 1.5, 2, 2.5, 3, 4, 5 m
You must set the link
partner transmit strength
to 400mV or greater.
Note
SFP-H10GB-CUxM10G DAC
Cisco Secure Firewall 3110, 3120, 3130, and 3140 Hardware Installation Guide
30
Overview
Supported SFP/SFP+/QSFP+ Transceivers
