Cisco 3750G-12S - Catalyst Switch - Stackable User Manual

2-32
Catalyst 3750 Switch Hardware Installation Guide
OL-6336-10
Chapter 2 Switch Installation
Connecting StackWise Cable to StackWise Ports
Figure 2-45 shows the correct removal procedure.
Figure 2-45 Correct Removal of the StackWise Cable from a StackWise Port
Caution Do not remove the cable by using the procedure shown in Figure 2-46.
Figure 2-46 Incorrect Removal of a StackWise Cable from a StackWise Port
CONSOLE
STACK 1
STACK 2
86826
CONSOLE
STACK 1
STACK 2
86827
