43-22
Catalyst 3750 Switch Software Configuration Guide
OL-8550-02
Chapter 43 Troubleshooting
Using the show platform forward Command
Using the show platform forward Command
The output from the show platform forward privileged EXEC command provides some useful
information about the forwarding results if a packet entering an interface is sent through the system.
Depending upon the parameters entered about the packet, the output provides lookup table results and
port maps used to calculate forwarding destinations, bitmaps, and egress information.
Note For more syntax and usage information for the show platform forward command, see the switch
command reference for this release.
Most of the information in the output from the command is useful mainly for technical support
personnel, who have access to detailed information about the switch application-specific integrated
circuits (ASICs). However, packet forwarding information can also be helpful in troubleshooting.
This is an example of the output from the show platform forward command on port 1 in VLAN 5 when
the packet entering that port is addressed to unknown MAC addresses. The packet should be flooded to
all other ports in VLAN 5.
Switch# show platform forward gigabitethernet1/0/1 vlan 5 1.1.1 2.2.2 ip 13.1.1.1 13.2.2.2
udp 10 20
Global Port Number:24, Asic Number:5
Src Real Vlan Id:5, Mapped Vlan Id:5
Ingress:
Lookup Key-Used Index-Hit A-Data
InptACL 40_0D020202_0D010101-00_40000014_000A0000 01FFA 03000000
L2Local 80_00050002_00020002-00_00000000_00000000 00C71 0000002B
Station Descriptor:02340000, DestIndex:0239, RewriteIndex:F005
==========================================
Egress:Asic 2, switch 1
Output Packets:
------------------------------------------
Packet 1
Lookup Key-Used Index-Hit A-Data
OutptACL 50_0D020202_0D010101-00_40000014_000A0000 01FFE 03000000
Port Vlan SrcMac DstMac Cos Dscpv
Gi1/0/1 0005 0001.0001.0001 0002.0002.0002
------------------------------------------
Packet 2
Lookup Key-Used Index-Hit A-Data
OutptACL 50_0D020202_0D010101-00_40000014_000A0000 01FFE 03000000
Port Vlan SrcMac DstMac Cos Dscpv
Gi1/0/2 0005 0001.0001.0001 0002.0002.0002
------------------------------------------
<output truncated>
------------------------------------------
Packet 10
Lookup Key-Used Index-Hit A-Data
OutptACL 50_0D020202_0D010101-00_40000014_000A0000 01FFE 03000000
Packet dropped due to failed DEJA_VU Check on Gi1/0/2
