Chapter 1 Overview
Network Configuration Examples
Figure 1-7 Catalyst 3750 Switch Stacks in Wiring Closets in a Backbone Configuration
Cisco 7x00 routers
Catalyst 6500
multilayer switches
Cisco IP Phones
with workstations
Aironet wireless
access points
IEEE 802.3af-compliant
powered device
(such as a web cam)
Cisco IP Phones
with workstations
WAN
IP IP
IP
IP IP
IP
86930
Catalyst 3750
multilayer
StackWise
switch stack
Catalyst 3750
multilayer
StackWise
switch stack
Aironet wireless
access points
IEEE 802.3af-compliant
powered device
(such as a web cam)
