2-2
Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router
OL-32185-02
Chapter 2 Cisco 4000 Series ISRs Preinstallation
Standard Warning Statements
General Safety Warnings
Warning
Read the installation instructions before you connect the system to its power source.
Statement
1004
Warning
Ultimate disposal of this product should be handled according to all national laws and
regulations.
Statement 1040
Warning
Installation of the equipment must comply with local and national electrical codes.
Statement
1074
Warning
To comply with the Class A emissions requirements shielded twisted pair T1/E1 cables must be
used for SPA-8-Port Channelized T1/E1 SPA (SPA-8XCHT1/E1) on the router.
EN55022/CISPR22 Statement
Warning
To comply with Class A emissions requirements- shielded management Ethernet, CON, and AUX
cables on the router must be used.
Warning
Power cable and AC adapter - When installing the product, please use the provided or designated
connection cables/power cables/AC adaptors. Using any other cables or adapters could cause a
malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of certified
cables (that have the ‘UL’ shown on the code) for any other electrical devices than products
designated by Cisco. The use of cables that are certified by Electrical Appliance and Material
Safety Law (that have ‘PSE’ shown on the code) is not limited to Cisco-designated products.
Statement 371
Warning
Only trained and qualified personnel should be allowed to install or replace this equipment
Statement 1030
Warning
This product relies on the building’s installation for short-circuit (overcurrent) protection.
Ensure that the protective device is rated not greater than: AC power supplies for the Cisco
4451-X ISR.
Statement 1005
Warning
This product requires short-circuit (overcurrent) protection to be provided as part of the
building installation. Install only in accordance with national and local wiring regulations.
Statement 1045
