Chapter 6 Install and Upgrade Internal Modules and FRUs
Install and Remove an SSD mSATA Storage Device
Step 6 Replace the chassis cover. See “Remove and Replace the Chassis Cover” section on page 6-4.
Remove the SSD mSATA Storage Device
To remove the SSD mSATA storage device:
Step 1 Read the “Safety Warnings” section on page 6-2 and disconnect the power supply before you replace any
module.
Step 2 Remove the chassis cover. For instructions on removing the chassis cover, see “Remove and Replace the
Chassis Cover” section on page 6-4.
Step 3 Unscrew the screws that attach the SSD mSATA storage device to the chassis. See Figure 6-48.
Step 4 The card should popup once the screws are removed.
Step 5 Install a new SSD mSATA memory device if needed. See Install the SSD mSATA Storage Device,
page 6-69.
Step 6 Replace the chassis cover. See “Remove and Replace the Chassis Cover” section on page 6-4.
1 Supplied screw 2 Supplied screw
3 Flash memory card 4 SSD mSATA storage device
5 Flash memory card connector 6 SSD mSATA connector

Cisco 4221 ISR Specifications

General

Form Factor	Rack-mountable
WAN Ports	2
LAN Ports	2
RAM	4 GB
Flash Memory	4 GB
Product Type	Router
Total Number of Ports	4
Number of Network (RJ-45) Ports	4
Number of Total Expansion Slots	3
Expansion Slot Type	NIM, ISC
Number of NIM Slots	2
Number of ISC Slots	1
Manageable	Yes
Power Supply	Internal
Redundant Power Supply	No
Authentication Method	RADIUS, TACACS+
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Operating Temperature	32°F to 104°F (0°C to 40°C)
Height	1.75 in
Encryption Algorithm	AES, 3DES
Dimensions (W x D x H)	1.75 x 13.5 x 1.73 inches
Operating Humidity	5 to 95% (noncondensing)
