Cisco 6851 Administration Guide

Step 4 Click Submit All Changes.
Configure the XML Directory Service
Procedure
Step 1 In the Phone Web page, click Admin Login > advanced > Voice > Phone.
Step 2 In the XML Directory Service Name field, enter the name of XML directory.
Step 3 In the XML Directory Service URL field, enter the url where XML directory is located.
Step 4 In the XML User Name field, enter the username of XML service.
Step 5 In the XML Password field, enter the password of XML service.
Step 6 Click Submit All Changes.
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
199
Phone Administration
Configure the XML Directory Service

Cisco 6851 Specifications

General

Network Protocols	SIP
Speakerphone	Yes
Bluetooth	No
Wi-Fi	No
USB Port	No
Display	3.5 inch grayscale display (396 x 162 pixels)
Ethernet	10/100 Ethernet
PoE	IEEE 802.3af
Audio	Wideband audio
Line Keys	4
Headset Port	RJ9
Supported Codecs	G.711, G.722, G.729, iLBC
Weight	0.9 kg
