Figure 1: Cisco IP Phone 6800 Series Multiplatform Phones
In this document, the terms Cisco IP Phone, phone, or device mean Cisco IP Phone 6800 Series Multiplatform
Phones.
Note
Cisco IP Phone 6821 Multiplatform Phones Connections
Connect your phone to your LAN with an Ethernet cable to enable full functionality of your phone. If your
Ethernet port is equipped with Power over Ethernet (PoE), you can power the phone through the LAN port.
If you don't have PoE available, then you need to use a power adapter to power the phone. Do not extend the
Ethernet cable outside the building. For your phone to work, it must be connected to the IP telephony network.
Figure 2: Cisco IP Phone 6821 Multiplatform Phones Connections
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
24
About the Cisco IP Phone
Cisco IP Phone 6821 Multiplatform Phones Connections

Table of Contents

Other manuals for Cisco 6851

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco 6851 and is the answer not in the manual?

Cisco 6851 Specifications

General IconGeneral
Network ProtocolsSIP
SpeakerphoneYes
BluetoothNo
Wi-FiNo
USB PortNo
Display3.5 inch grayscale display (396 x 162 pixels)
Ethernet10/100 Ethernet
PoEIEEE 802.3af
AudioWideband audio
Line Keys4
Headset PortRJ9
Supported CodecsG.711, G.722, G.729, iLBC
Weight0.9 kg
