Cisco 6851 Administration Guide

• Elapsed time—Total time elapsed since the last reboot of the system
• Tx (Packets)—Transmitted packets from the phone.
• Rx (Packets)—Received packets from the phone.
View the Status Messages on the Phone
Procedure
Step 1 Press Applications .
Step 2 Select Status > Status messages.
You can view a log of the various phone statuses since provisioning was last done.
Status messages reflect UTC time and are not affected by the timezone settings on the phone.
Note
Step 3 Press Back.
View the Network Status
Procedure
Step 1 Press Applications .
Step 2 Select Status > Network Status.
You can view the following information:
• Network type—Indicates the type of Local Area Netwrok (LAN) connection that the phone uses.
• Network status—Indicates if the phone is connected to a network.
• IPv4 status—IP address of the phone. You can see information on IP address, Addressing type, IP status,
Subnet mask, Default router, Domain Name Server (DNS) 1, DNS 2 of the phone.
• IPv6 status —IP address of the phone. You can see information on IP address, Addressing type, IP
status, Subnet mask, Default router, Domain Name Server (DNS) 1, DNS 2 of the phone.
• VLAN ID—VLAN ID of the phone.
• MAC address—Unique Media Access Control (MAC) address of the phone.
• Host name—Displays the current host name assigned to the phone.
• Domain—Displays the network domain name of the phone. Default: cisco.com
• Switch port link—Status of the switch port.
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
205
Phone Troubleshooting
View the Status Messages on the Phone

Cisco 6851 Specifications

General

Network Protocols	SIP
Speakerphone	Yes
Bluetooth	No
Wi-Fi	No
USB Port	No
Display	3.5 inch grayscale display (396 x 162 pixels)
Ethernet	10/100 Ethernet
PoE	IEEE 802.3af
Audio	Wideband audio
Line Keys	4
Headset Port	RJ9
Supported Codecs	G.711, G.722, G.729, iLBC
Weight	0.9 kg
