Page #312 background imageLoading...
Page #312 background image
DescriptionParameter
The Uniform Resource Identifier (URI) of the Busy
Lamp Field (BLF) list that you have set up for a user
of the phone, on the BroadSoft server.
This field is only applicable if the phone is registered
to a BroadSoft server. The BLF list is the list of users
whose lines the phone is allowed to monitor. See
Phone Configuration for Monitoring Other Phones,
on page 162 for details.
The BLF List URI must be specified in the format
<URI name>@<server>. The BLF List URI
specified must be the same as the value configured
for the List URI: sip parameter on the BroadSoft
server.
Default: Blank
Example XML configuration:
<BLF_List_URI
ua="na">MonitoredUsersList@sipurash22.com</BLF_List_URI>
BLF List URI
Controls whether the phone uses its line keys to
monitor the BLF list, when monitoring of the BLF
list is active.
When set to No, the phone uses only the Key
Expansion Module keys to monitor the BLF list.
This setting only has significance when BLF List is
set to Show.
Default: No
Example XML configuration:
<Use_Line_Keys_For_BLF_List
ua="na">Yes</Use_Line_Keys_For_BLF_List>
Use Line Keys For BLF List
Cisco IP Phone 6800 Series Multiplatform Phones Administration Guide
298
