Cisco 7600 Series Hardware

9
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 15S
OL-10362-13
Guide to Supported Hardware for Cisco 7600 Series Routers with Cisco IOS Release 12.2SR
Supported Hardware
Supervisor Engine 720 Common Features
• Integrated 720-Gbps Switch Fabric
• 64-MB bootflash device
• 2 CompactFlash Type II slots (disk0 and disk1)
Note Some Supervisor Engine 720 Release 12.2SR images are larger than the bootflash device
and must be stored on a CompactFlash card.
• Two Ethernet uplink ports:
– 1-MB packet buffer per port
– Port 1—Gigabit Ethernet SFP
– Port 2—Configurable as Gigabit Ethernet SFP or 10/100/1000 Mbps RJ-45
• QoS port architecture (Rx/Tx): 1p1q4t/1p2q2t
• Port grouping:
– Number of ports: 2
– Number of port groups: 1
– Port ranges per port group: 1–2
• Supervisor Engine 720 requires a high-capacity fan tray (see the “Fan Trays” section on page 113)
Supervisor Engine 720 with PFC3BXL
Note There are no memory upgrade options for WS-SUP720-3BXL.
Product ID
(append “=” for spares)
Power
Required Product Description
Minimum
Software Version
WS-SUP720-3BXL
7.82 A@42 V Supervisor Engine 720 with PFC3BXL:
• 1-GB DRAM
• Policy Feature Card 3BXL (PFC3BXL); see the
“RSP720-3C-10GE” section on page 19
• Multilayer Switch Feature Card 3 (MSFC3):
– 1-GB DRAM
– 64-MB bootflash
12.2(33)SRA

Cisco 7600 Series Specifications

General

Category	Network Router
Port Density	Varies by module
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet
Redundancy	Power supplies
Power Supply	AC or DC, Redundant options available
Operating System	Cisco IOS XR
Management	CLI, SNMP
Form Factor	Modular
Dimensions	Varies by chassis model
Weight	Varies by chassis model and configuration
Chassis Slots	6, 9, or 13
